Electrical Performance Parameters (STC)

Model	COM-Z2-T10	COM-Z2-T20	COM-Z2-T40	COM-Z2-T60
Etching Removal Rate %	10	20	40	60
Maximum Rated Power Pmax (W)	240	210	160	100
Power Tolerance %	±3	±3	±3	±3
Maximum Power Point Voltage Vmpp (V)	146.3	146.3	146.3	146.3
Maximum Power Point Current Impp (A)	1.66	1.47	1.10	0.73
Open Circuit Voltage Voc (V)	182.3	182.3	182.3	182.3
Short Circuit Current Isc (A)	1.99	1.69	1.26	0.84

STC (Standard Test Conditions): Irradiance 1000W/m², Cell Temperature 25°C, Air Mass AM1.5

Operating Parameters

Parameter	Value
Maximum System Voltage	1000V
Reverse Current Withstand Threshold	T10-2.8A / T20-2.5A / T40-1.8A / T60-1.2A
Operating Temperature	-40°C ~ +85°C
Maximum Static Load	5400Pa
Hail Test	Passed
Protection Class	IP67
