Electrical Performance Parameters (STC)

Model	COM-CA2-T30	COM-CA2-T40	COM-CA2-T50
Etching Removal Rate %	30	40	50
Maximum Rated Power Pmax (W)	200	170	140
Power Tolerance	±3	±3	±3
Maximum Power Point Voltage Vmpp (V)	146.3	146.3	146.3
Maximum Power Point Current Impp (A)	1.43	1.23	1.02
Open Circuit Voltage Voc (V)	182.3	182.3	182.3
Short Circuit Current Isc (A)	1.64	1.41	1.17

STC (Standard Test Conditions): Irradiance 1000W/m², Cell Temperature 25°C, Air Mass AM1.5

Operating Parameters

Parameter	Value
Maximum System Voltage	1000V
Reverse Current Withstand Threshold	T30-2.3A / T40-1.9A / T50-1.6A
Operating Temperature	-40°C ~ +85°C
Maximum Static Load	2400Pa / 3600Pa
Hail Test	Passed
Protection Class	IP67
